Photonic Universe Iconica Hybrid Pure Sine Wave Inverters - 10000W 48V

High-capacity hybrid inverter for reliable off-grid power and instant backup performance.

Power large off-grid systems with the Iconica MAX 10000W hybrid inverter that combines an inverter, dual-input MPPT controller, and a powerful smart charger in one unit. It can use energy from solar, mains, generator, or batteries, and can even run appliances directly from solar without needing a battery. With UPS backup and advanced smart settings, it keeps power stable even in areas with frequent outages.

Compatibility

This hybrid inverter is suitable for 48V flooded, sealed GEL/AGM lead-acid and Lithium batteries with pre-defined charging programs (consult the battery supplier for advice on Lithium battery charging settings). A user-defined battery type with numerous customisable settings is also available for charging other battery types.

If you are unsure whether 10000W is enough for your appliances, please refer to the following table: Table of typical power consumption of domestic appliances.

Key Functions

• 10000W 48V Pure sine wave inverter:
  • Converts DC power into 230V AC to run household appliances including TVs, laptops, fridges, microwaves, and lighting. Delivers 10,000VA continuous output with up to 20,000VA peak for starting heavy motor-driven devices like pumps, power tools, and vacuum cleaners. Pure sine wave technology ensures maximum efficiency and broad appliance compatibility, outperforming modified sine wave inverters.
• Inbuilt 10000W high solar input MPPT Solar charge controller:
  • Supports two independent solar inputs, each up to 5000W. The MPPT charge controller manages up to 100A with full protection against overcharge, overheating, reverse current, and more. Advanced MPPT technology maximizes solar output at up to 98% efficiency, making it ideal for large or dual arrays with different panels or light conditions. Solar performance data is clearly shown on the LCD display.
• Enhanced 150A  Smart battery charger:
  • Enables safe, efficient, and fast unattended battery charging from mains or a generator at up to 150A, with multi-stage charging and full overcharge protection.
• System expansion potential:
  • Can be paralleled with up to five identical inverters, allowing system expansion to as much as 60kW. Once paralleled, 3-phase operation becomes available for powering industrial equipment and machinery.

The Iconica MAX 10000W 48V hybrid inverter boasts an abundance of unique features, providing enhanced functionality over standard inverters. These include:

• Load power without a battery:
  • Can power AC loads directly from solar panels without requiring a battery, creating a highly efficient and independent system with minimal energy loss. If batteries are connected, the inverter can run appliances and charge the battery bank simultaneously. For example, with 4000W of solar input, 2000W may power appliances while the remaining 2000W charges the batteries.

• Output source priority:
  • This intelligent feature allows the user to set output source preferences (solar/ battery power/ mains input or a generator) for the AC load output of the inverter. This menu includes several options for varying conditions and scenarios, e.g. which source of energy is given priority for the AC output if solar power is insufficient/ if battery voltage is too low/ if mains is unavailable, etc.
• Battery charging priority:
  • Offers extensive battery charging priority settings, allowing the user to charge via solar only, mains only, or a combination of both.
• A range of highly customisable settings:
  • Features highly customizable settings through a user-friendly interface. Users can adjust AC input range, battery type, charging current, voltage cut-offs and recovery behavior, charging stage durations, auto-restart, power-saving modes, overload bypass, battery equalization, and more. Even operational elements like alarms and backlight can be individually configured.
• DC output connectors:
  • Provides emergency backup for DC-powered devices like routers, modems, surveillance systems, set-top boxes, and other critical telecom equipment. Features three 3A channels that can be manually activated or disabled via the LCD or the DC jack power switch.
• Illuminated LCD screen:
  • The 5-inch color LCD provides clear, comprehensive information, easily navigated via four touch function keys. Displays include status, mode, input/output voltage, frequency, battery voltage, load power, charge/discharge current, real-time clock, and daily/monthly/yearly energy generation.
• Customisable built-in RGB light ring:
  • Customizable color display shows battery capacity, energy source, charge/discharge status, solar input, and load percentage, offering an intuitive, at-a-glance view of system status.
• Advanced communication options:
  • Includes PC connection with software for viewing system data (solar, battery, AC voltage, charge current, battery capacity) and exporting logs to PDF/Excel. Optional Wi-Fi kits enable online monitoring, remote access, and email/push notifications for enhanced control and insights.
• Auto restart function:
  • Automatically disconnects loads during overload or overheating and reconnects once conditions are safe.
• Generator auto-start function:
  • Can trigger a generator via dry contacts to start automatically when battery voltage falls below a set level.
• Intelligent cooling design:
  • Uses predictive fan control with variable speeds (1–3 fans) to prevent component overheating.

*Supplied with USB drive, PC connection cable and PC software CD.*
